Anti-static Self-leveling Coating
Applications:
Electronics,communications,printing,computer room,precision mechanical instrumentation,powder,chemistry.military, aerospace and other places that require anti-static.It is especially suitable for the production workshop andstorage area of electronic instruments and meters,integratedcircuits and other components with high sensitivity to staticelectricity.
Coating properties:
- With all the excellent properties of epoxy mortar coating
- It can quickly leak electrostatic charge
- Long-lasting anti-static effect
- Not affected by time, temperature, humidity
- Environmental protection, no pollution, non-toxic
Products Categories
Get A Free Quote
Technical Index
| Pilot projects | unit | index | |
|---|---|---|---|
| Dry | Actual Dry | h | ≤4 |
| Time(25℃ ) | Actual Dry | h | ≤24 |
| Pencil hardness | – | ≥2H | |
| Impact resistance (500g steel ball) | g.cm | Pass | |
| Wear resistance (750g/500r) | g | ≤0.03 | |
| Adhesion(grid method) | level | 1 | |
| Adhesion(Grid method) | Middle coat | Ω | 1.0×10（4）-1.0×10（5） |
| Topcoat | Ω | 2.5×10（4）-1.0×10（9） | |
| Volume resistance | Ω | 1.0×10（4）-1.0×10（9） | |
Construction procedure
| Construction method | Auxiliary material | Reference dosage | |
|---|---|---|---|
| Plain land | Do waterproofing | / | / |
| Primer coat | Scraping epoxy primer | / | 0.15kg/m² |
| Mortar layer | Scraping epoxy mortar layer | Quartz sand | 0.25-0.7kg/m² |
| Putty layer | Scraping epoxy putty layer | / | 0.1kg/m² |
| Laying Copper Foil | Laying Copper Foil | / | / |
| Conductive Coating | Scrape and roll conductive midcoat | / | 0.12kg/m² |
| Topcoat | Trowelling anti-static self-leveling topcoat | / | 0.65-0.7kg/m² |
