Anti-static Flat Coating
Applications:
Applicable to electronics, communications, printing,computer room, precision machinery, powder chemistry ordnance, aerospace and other places that need to prevent static electricity.
Coating properties:
- With all the excellent properties of epoxy mortar floor coating
- Can quickly leak electrostatic charge
- Long-lasting anti-static effect
- Not affected by time, temperature, humidity
Products Categories
Get A Free Quote
Technical Index
| Pilot projects | unit | index | |
|---|---|---|---|
| Dry | Actual Dry | h | ≤4 |
| Time(25℃ ) | Actual Dry | h | ≤24 |
| Pencil hardness | – | ≥2H | |
| Impact resistance (500g steel ball) | g.cm | Pass | |
| Wear resistance (750g/500r) | g | ≤0.03 | |
| Adhesion(grid method) | level | 1 | |
| Surface resistance | Middle coat | Ω | 1.0×10（4）-1.0×10（5） |
| Topcoat | Ω | 2.5×10（4）-1.0×10（9） | |
| Volume resistance | Ω | 1.0×10（4）-1.0×10（9） | |
Construction procedure
| Construction method | Auxiliary material | Reference dosage | |
|---|---|---|---|
| Plain land | Do waterproofing | / | / |
| Primer coat | Scraping epoxy primer | / | 0.15kg/m² |
| Mortar layer | Scraping Intermediate emortar layer | Quartz sand | 0.25-0.7kg/m² |
| Putty layer | Scraping epoxy putty layer | / | 0.1kg/m² |
| Copper foil laying | Laying Copper Foil | / | 0.25-3.0kg/m² |
| Conductive Midcoat | Scrape and roll conductive midcoat | / | 0.12kg/m² |
| Topcoat | Roller to apply Topcoat anti-static | / | 0.15-0.18kg/m² |
